Reliable Onboard Connectivity
Provides stable wireless connectivity with broad, reliable coverage across wide areas of the vessel.
Quick and
Easy Installation
Installs easily on both newbuilds and operating vessels, with minimal
downtime and disruption.
Reduced
Maintenance Cost
Offers a significant cost advantage with reduced maintenance requirements, adding long-term value for shipowners.
Enhanced
Safety
Removes shadow zones in steel structures, supporting safer shipbuilding and operations.
metalVox®, Benefits
Ensure seamless communication at sea with metalVox®, a system built for performance and safety.
2
Number of Channels
1
15
Weight (Approx., kg)
7
446 x 700 x 193
Dimensions (L × W × H, mm)
362 x 350 x 151
metalVox® Di-Station Ⅱ
metalVox® Station Ⅱ
Specifications
Not supported
Magnetic Bracket
Supported (optional)
Frequency Range
400 ~ 470 MHz (UHF)
Output TX PWR
4.8 W
Channel Spacing
12.5 kHz
Operating Temp.
-20 ~ 55 ℃
Nominal PWR Rating
24 V DC
Idle: 450, TX: 3000
Current (mA, @24V DC)
Idle: 250, TX: 1500
Connection
External Antenna (N-Type)
Alarm Input
Supported via a Dry Contact
Installation Type
Bracket-Mounted
Protection Rating
IP56
Compliance
IEC 60945, DMR, KC Certified
* metalVox® Station Ⅱ devices are also available with enhanced audio clarity and reduced voice delay.
Specifications
Specifications are subject to change without prior notice.
metalVox® Product Lineup
The metalVox® Single and Dual Series products are designed to meet every communication need onboard.
Optional Products
Molded
metalVox® Antenna
MTPAUV1F-001
Enclosure
Model Number
Product Name
Molded
metalVox® Beacon
DMBU0V2F
Flame Retardant PC
PSU-24 (Power Supply Unit)
PSUDCV1F-001
metalVox® Antenna
metalVox® Beacon
PSU-24(Power Supply Unit)
metalVox® Dual Series
Aluminum
Dual
metalVox® Di-Station Ⅱ
MTZ00W2F
Enclosure
Channel
Model Number
Product Name
Aluminum
Dual
metalVox® Di-Booster
MTZBOW1F-001
metalVox® Di-Station Ⅱ
metalVox® Di-Booster
metalVox® Single Series
Aluminum
Single
metalVox® Booster
MTZBOV3F
Aluminum
Single
metalVox® Station Ⅱ
MTZPLV1F
Enclosure
Channel
Model Number
Product Name
metalVox® Station Ⅱ
metalVox® Booster
metalVox®, Clear Voice Through metalWave®
metalVox®, a radio communication system featuring our proprietary metalWave® technology,
is designed to ensure reliable connectivity in metal-rich shipboard environments.
Certified, Globally Compliant Technology
-
IEC 60945 Maritime navigation and radiocommunication equipment and systems
-
IEC 60529 Ingress Protection: Rated for IP56
-
ETSI TS 102 361 Digital protocol (DMR) compliance
-
KC Certified
metalVox® in service on large merchant vessels across diverse ship types.
Stay Connected. Wherever You Are, Whenever You Call.
metalVox® is a marine wireless communication system
featuring ZN TECHNOLOGIES’ proprietary metalWave® technology.
metalVox®
Product > metalVox
metalVox® delivers field-proven performance across diverse vessel types.
Proven Vessel Applications
BULK (Bulk Carrier)
180K BULK
VLCC (Crude Oil Carrier)
VLCC
PCTC (Pure Car & Truck Carrier)
7,000 / 8,600 CEU PCTC
LNGC / LPGC / FSRU
174K LNGC / 45K LPGC / 170K FSRU
CNTR (Container Ship)
7,300 / 8,000 / 9,000 / 13,000 TEU CNTR
Cargo Ship Specifications
Cargo Ship Types
• Contact us for a wide range of Motorola radio accessories available with your system.
• The metalVox® system and Motorola DMR radios can be provided as a
complete package, ensuring optimal performance and simplified procurement.
• Replacement radios can be supplied pre-configured for the specific vessel.
• Each radio is uniquely configured to prevent interference with other vessels.
The metalVox® system is fully compatible with Motorola DMR radios,
which are delivered pre-configured for seamless integration at deployment.
Radio Compatibility
metalVox® Installation Cases & On Board Testing
Field installations and on-board verification carried out across diverse vessel types.
Installation Cases
Installation Cases
On Board Testing
On Board Testing
Installation & Results
Installation & Results
metalVox® Installation Cases & On Board Testing
Field installations and on-board verification carried out across diverse vessel types.
Installation & Results
On Board Testing
Installation Cases
Installation & Results
On Board Testing
Installation Cases
The metalVox® system and Motorola DMR radios can be provided as a complete package, ensuring optimal performance and simplified procurement.
•
The metalVox® system and Motorola DMR radios can be provided as a complete package, ensuring optimal performance and simplified procurement.
•
Replacement radios can be supplied pre-configured for the specific vessel.
•
Each radio is uniquely configured to prevent interference with other vessels.
•
Each radio is uniquely configured to prevent interference with other vessels.
•
Replacement radios can be supplied pre-configured for the specific vessel.
•
The metalVox® system and Motorola DMR radios can be provided as a complete package, ensuring optimal performance and simplified procurement.
•
Contact us for a wide range of Motorola radio accessories available with your system.
•
The metalVox® system is fully compatible with Motorola DMR radios, which are delivered pre-configured for seamless integration at deployment.
Radio Compatibility
metalVox® delivers field-proven performance across diverse vessel types.
BULK
Bulk Carrier
180K BULK
VLCC
Crude Oil Carrier
VLCC
PCTC
Pure Car & Truck Carrier
7,000 / 8,600 CEU PCTC
LNGC
LPGC
FSRU
174K LNGC / 45K LPGC / 170K
FSRU
CNTR
Container Ship
7,300 / 8,000 / 9,000 / 13,000
TEU CNTR
Cargo Ship
Specifications
Cargo
Ship Types
Proven Vessel Applications
Enhanced Safety
Removes shadow zones in steel structures, supporting safer shipbuilding and operations.
Reduced Maintenance Cost
Offers a significant cost advantage with reduced maintenance requirements, adding long-term value for shipowners.
Quick and Easy Installation
Installs easily on both newbuilds and operating vessels, with minimal downtime and disruption.
Reliable Onboard Connectivity
Provides stable wireless connectivity with broad, reliable coverage across wide areas of the vessel.
Ensure seamless communication at sea with metalVox®, a system built for performance and safety.
metalVox®, Benefits
* metalVox® StationⅡ devices are also available with enhanced audio clarity and reduced voice delay.
IEC 60945, DMR, KC Certified
Compliance
IP56
Protection Rating
Bracket-Mounted
Installation Type
Supported via a Dry Contact
Alarm Input
External Antenna (N-Type)
Connection
Idle: 450,
TX: 3000
Idle: 250,
TX: 1500
Current
(mA, @24V DC)
24 V DC
Nominal PWR Rating
-20 ~ 55 ℃
Operating Temp.
12.5 kHz
Channel Spacing
4.8 W
Output
TX PWR
400 ~ 470 MHz (UHF)
Frequency
Range
Not
supported
Supported (optional)
Magnetic
Bracket
2
1
Number of
Channels
15
7
Weight
(Approx, kg)
446 x 700 x 193
362 x 350 x 151
Dimensions
(L×W×H, mm)
metalVox®
StationⅡ
Specifications
metalVox®
Di-StationⅡ
Specifications
Specifications are subject to change without prior notice.
The metalVox® Single and Dual Series products are designed to meet every communication need onboard.
metalVox®
Product Lineup
metalVox® Single Series
metalVox® Booster
metalVox® Station Ⅱ
Aluminum
Single
MTZBOV3F
metalVox®
Booster
Aluminum
Single
MTZPLV1F
metalVox®
StationⅡ
Enclosure
Channel
Model Number
Product Name
metalVox® Dual Series
metalVox® Di-Booster
metalVox® Di-Station Ⅱ
Aluminum
Dual
MTZBOW1F-001
metalVox®
Di-Booster
Aluminum
Dual
MTZ00W2F
metalVox®
Di-StationⅡ
Enclosure
Channel
Model Number
Product
Name
PSU-24(Power Supply Unit)
metalVox® Beacon
metalVox® Antenna
Flame Retardant PC
PSUDCV1F-001
PSU-24
(Power Supply Unit)
Molded
DMBU0V2F
metalVox®
Beacon
Molded
MTPAUV1F-001
metalVox®
Antenna
Enclosure
Model Number
Product Name
Optional Products
metalVox®, Clear Voice
Through metalWave®
metalVox®, a radio communication system featuring our proprietary metalWave® technology, is designed to ensure reliable connectivity in metal-rich shipboard environments.
metalVox® in service on large merchant vessels across diverse ship types.
Certified, Globally Compliant Technology
IEC 60945 Maritime navigation and radiocommunication equipment and systems
•
IEC 60529 Ingress Protection: Rated for IP56
•
ETSI TS 102 361 Digital protocol (DMR) compliance
•
KC Certified
•
metalVox® is a marine wireless communication system featuring ZN TECHNOLOGIES’ proprietary metalWave® technology.
